PVE30 – Residential Elevator
Single Passenger Residential Elevator
30″ Inch Exterior Diameter
350 lbs Capacity
As the world’s smallest residential elevator, the PVE30 has quickly found its place as the ultimate space-saving solution for any home. If you are in need of a home lift, but are limited in space, the Single-Passenger Residential Elevator is the perfect solution for you.
Single Passenger Residential Elevators
The PVE30 is the smallest residential elevator in the world, yet it is just as capable as other residential elevators that are much larger and much more expensive. The PVE30 elevator has a 350lb (159kg) lift capacity and is capable of up to 50 ft. (15m) of rise over as many as five stops. With a 30 inch outside diameter, these home elevators are small enough to fit in even the most modest-sized home. If you thought home elevators were out of reach for you because of size constraints, this is the solution you have been looking for.
No Pre-Construction Pit, Hoist Way or Machine Room Required
This home lift was designed as a compact and cost-effective alternative to taking the stairs, and are ideal home elevators for townhouses and other tight areas where traditional residential elevators wouldn’t even be a consideration. As the smallest of the three vacuum elevator models, it only requires a 32-inch finished through floor hole for the elevator cylinder (and you!) to pass through. Rather than requiring a large elevator shaft, this self-contained home lift rests on the existing ground floor and provides a beautiful panoramic view as you travel from floor to floor within your home. During the ascent or descent, you will enjoy cool, ambient temperatures as a cabin fan circulates the air in the cabin and an LED light keeps the cabin lit.
Eco‐Friendly Home Elevators
All that is needed to power this mighty elevator is 220V, 25 Amp, single phase service. This is roughly the same as what your washer and dryer use. From an environmental and cost-saving standpoint, the PVE30 draws the least amount of electricity out of all our home lift models. Just like the other models in our lineup, these residential elevators do not even use electricity to descend. Not only will your life be a lot easier now that you can avoid the stairs, but your electric bill will barely change!
Precision Engineering
Just because it is small doesn’t mean these residential elevators are any less capable or any less quality-made. It is manufactured from polycarbonate and aluminum, making it one of the best home elevators on the market today. Place your confidence in our PVE30 residential elevators and you won’t be disappointed.
Residential Elevators – PVE30
Standard Features
- No pit, hoist way, or machine room required
- 50 ft (15m) Total Rise Max
- 35 ft/M travelling speed
- Two to Five Stops
- External cylinder diameter: 30 inches (750mm)
- Internal cabin diameter: 20 ½ inches (521mm)
- Internal cabin height: 6’7” (79 inches/ 2005mm)
- Entrance way opening: 20 ½ inches (521mm)
- Through Floor or Balcony Mount Landings
- Power Supply: 25 AMP 220VAC
- In-line door openings
- Aluminum and polycarbonate cylinder structure
- Automatic interior LED lighting and fan
- Mechanical emergency safety brake system
- One year limited manufacturer warranty
- ASME A17.7 Certified
OPTIONS
COLORS
- Color Chart
- Standard Dark Gray
- Light Gray
- White
- Black
- Taupe
- Anodized Silver
UPGRADES & FEATURES
- Smart Home Integration
- Solar Panel Package
- Homing Feature
- Remote Control Option
- Phone
- Cabin Key Lock
- Earthquake Brackets
CUSTOMIZATIONS
- Clear Polycarbonate Panels
- Custom Right Hand Door
DOOR OPENING OPTIONS
DRAWINGS & SPECS
Space-Saving, Easy to Use Home Elevators with Low Maintenance
This compact vacuum elevator system is the choice of many homeowners because of its small size, but that’s not it’s only advantage. PVE30 residential elevators offer several benefits for homeowners who use a wheelchair to get around or have other mobility issues. There’s the ease of maintaining this compact pneumatic elevator: Because vacuum elevators use air pressure to operate, thus eliminating the need for shafts or machine rooms, they also have fewer moving parts — which means less maintenance. Along with their sleek style, these home elevators are also durable and reliable. And without the need for a traditional elevator shaft, our vacuum elevators also offer better visibility, inside and out. Low maintenance is also among the benefits of owning a space-saving PVE30 residential elevator as compared to traditional shaft-style elevators. However, like all machinery, home elevators require regular inspections and need to be maintained properly to keep them running smoothly.
What Are the Maintenance Requirements For the PVE30 Home Lift?
Our residential home elevators are surprisingly easy to install and maintain. The installation takes 1-3 days, and the impact on your home is minimal. Any maintenance required for these residential elevators is always expedient and minimally invasive to your daily schedule. A manufacturer’s study shows that pneumatic elevators need maintenance once every 5 years, or about 15,000 lifts, to replace the main seal. This is only a minor inconvenience compared to a traditional elevator that requires frequent inspections, annual maintenance, and costly parts that must be routinely replaced.
Low maintenance is just one of the features that make our residential elevators PVE30 perfect for homeowners who have mobility issues, but still demand superior function and minimal hassle from their accessibility equipment.
Servicing Over 90+ Countries Globally
Elegantly Designed Residential Elevators
At PVE, our mission is to create home elevator solutions in which design and
technology coincide. Where the utilization of attractive materials and the application of
fundamental physics combine to produce an innovative & aesthetically pleasing elevator
that enhances homeowners…
Residential Elevator Components And Innovative Solution
By using Pneumatic Technology® to generate areas of higher and lower pressure within the cylinder hoistway, Residential Elevators of PVE combine a vertical cylinder with a fully enclosed car that smoothly moves up and down through air suction and gravity.
Foundation of Home Elevators
Founded in 2002 – Pneumatic Vacuum Elevators, LLC (PVE) is the inventor and sole manufacturer of the world’s only Air-Driven Home Elevator, the Pneumatic Elevator. Powered by the most abundant resource in the world, AIR, Pneumatic Elevators are innovative, space-saving…
TESTIMONIALS
I thoroughly enjoy riding in my PVE elevator as its extremely comfortable… I would unhesitatingly, recommend it to people who are confined to a wheelchair like myself, to me it’s that good and reliable!
Tamara Gordon
My house was built in 1925 and it was hard to get something to fit in with the décor of my home, but the PVE fit in perfectly. I am thrilled with the design, engineering, and reliability of the vacuum elevator.
Stan Barth
Highly recommend. Working with PVE was such an incredible experience! From our very first meeting they were so professional, time efficient & helpful. Couldn’t be happier. Our elevator is heaven sent. Thank you PVE & team.
Kim Klotz
Residential Elevator Manufacturers
Pneumatic Vacuum Elevators LLC is the designer and manufacturer of the vacuum elevator.
PVE currently manufactures three versions of its air driven residential elevators, ranging from single to a three-passenger, wheelchair accessible home lift. All of PVE’s vacuum home lift systems are capable of up to a 50 foot (15m) vertical rise over as many as five stops. The unique design of our vacuum residential elevators is a perfect choice for any retrofit or new construction project and will enhance the value of one’s home without the consuming footprint of traditional home elevators. These innovative home elevators do not require any pre-construction shaft, pit or machine room and can be installed in as little as two to three days. By using a vacuum pump to generate areas of higher and lower atmospheric pressure within the cylinder hoist way, the unit smoothly moves between floors while using much less energy than other home elevators.
