RESIDENTIAL ELEVATOR – PVE30 ECO
Single Passenger Home Elevator
30” Inch Exterior Diameter
350 lbs Capacity
As PVE’s Economical Residential Elevator, the PVE30 Eco is the ideal cost-effective solution for any 2-Stop Home Elevator Installation. Available for 2-Levels, this single-passenger home elevator is the smallest residential elevator on the market saving homeowners money and space while providing the highest quality materials and innovative features.
PVE30 Eco Features
2-Stop Residential ElevatorS
Economical Home Elevators Designed for 2-Level Installations
30” inch Exterior Diameter Saves Space Inside Home
Rests on Existing Ground Floor. No Shaft, pit or machine room required
Transport 1 Passenger with 350 lb Lift Capacity
Installation in a Little as 2-3 Days
PLUG & PLAY ELEVATOR
220 Volt, Single Phase Power Supply
No Harmful Oils, Gases or Lubricants Required
Cost-Effective Alternative to Stairs
PVE30 Eco is the smallest residential elevator in the world, yet it is just as capable as other residential elevators that are much larger and much more expensive. Designed as an economical home elevator solution for 2-Story Applications, the PVE30 Eco has a total exterior diameter of 30 inches making it small enough to fit in even the most modest sized home. Able to transport 1 passenger with a 350lb (159kg) lift capacity, the PVE30 Eco is the ideal space saving solution for any 2-level project and can to be installed in locations other home elevators can not.
2-Story Home Elevators
Rather than requiring a large elevator shaft, these self-contained home elevators rest on the existing ground floor and provide a beautiful panoramic view as you travel from floor to floor within your home. Custom built to the height of your 2-level home, this innovative home elevator was designed as a compact and cost-effective alternative to taking the stairs, and is ideal for tight areas where traditional residential elevators wouldn’t even be a consideration. As the smallest of the three vacuum elevator models, it only requires a 32-inch finished through floor hole for the elevator cylinder (and you!) to pass through. During the ascent or descent, you will enjoy cool, ambient temperatures as a cabin fan circulates the air in the cabin and an LED light keeps the cabin lit.
Quick & Easy Installation
With it’s small footprint and minimal pre-construction requirements, the PVE30 Eco offers the quickest installation and lowest energy consumption of all our home elevator models. Able to be install in as little as 2-3 days, this eco-friendly home lift can easily be added to any retro-fit or new construction project. Designed as Plug & Play residential elevators, all that is needed to power these space saving home elevators is 220V, 25 Amp, single phase service. This is roughly the same as what your washer and dryer use.
Eco-Friendly Residential Elevator
Not only will your life be a lot easier now that you can avoid the stairs, but your electric bill will barely change! From an environmental and cost-saving standpoint, the PVE30 draws the least amount of electricity out of all home elevators. Just like the other models in our lineup, it does not even use electricity to descend. In addition, the PVE30 Eco is manufactured from polycarbonate and aluminum, making it one of the best residential elevators on the market today. Place your confidence in our PVE30 Eco residential elevators and you won’t be disappointed.
Residential Elevator – PVE30 ECO
- No pit, hoist way, or machine room required
- 50 ft (15m) Total Rise Max
- 35 ft/min travelling speed
- Two Stop Applications
- External cylinder diameter: 30 inches (750mm)
- Internal cabin diameter: 20 ½ inches (521mm)
- Internal cabin height: 6’7” (79 inches/ 2005mm)
- Entrance way opening: 20 ½ inches (521mm)
- Through Floor or Balcony Mount Landings
- Power Supply: 25 AMP 220VAC
- In-line door openings
- Aluminum and polycarbonate cylinder structure
- Automatic interior LED lighting and fan
- Mechanical emergency safety brake system
- One year limited manufacturer warranty
- ASME A17.7 Certified
- Color Chart
- Standard Dark Gray
- Light Gray
- Anodized Silver
UPGRADES & FEATURES
- Solar Panel Package
- Smart Home Integration
- Homing Feature
- Remote Control Option
- Cabin Key Lock
- Earthquake Brackets
- Clear Polycarbonate Panels
- Custom Right Hand Door
DOOR OPENING OPTIONS
DRAWINGS & SPECS
I thoroughly enjoy riding in my PVE elevator as its extremely comfortable… I would unhesitatingly, recommend it to people who are confined to a wheelchair like myself, to me it’s that good and reliable!
My house was built in 1925 and it was hard to get something to fit in with the décor of my home, but the PVE fit in perfectly. I am thrilled with the design, engineering, and reliability of the vacuum elevator.
Highly recommend. Working with PVE was such an incredible experience! From our very first meeting they were so professional, time efficient & helpful. Couldn’t be happier. Our elevator is heaven sent. Thank you PVE & team.
Residential Elevator Manufacturers
Pneumatic Vacuum Elevators LLC is the designer and manufacturer of the vacuum elevator.
PVE currently manufactures three versions of its air driven residential elevators, ranging from single to a three-passenger, wheelchair-accessible home elevator. All of PVE’s vacuum home lift systems are capable of up to a 50 foot (15m) vertical rise over as many as five stops. The unique design of the vacuum residential elevator is a perfect choice for any retrofit or new construction project and will enhance the value of one’s home without the consuming footprint of traditional residential elevators. These innovative residential elevators do not require any pre-construction shaft, pit or machine room and can be installed in as little as two to three days. By using a vacuum pump to generate areas of higher and lower atmospheric pressure within the cylinder hoist way, the unit smoothly moves between floors while using much less energy than other home elevators.
